BMW E-SERIES WALBRO 255LPH STAGE 1 LPFP UPGRADE

These kits are designed to be installed in line with your stock low-pressure fuel pump (LPFP). They provide approximately 50% more flow when combined with your stock pump.

• Complete Kit:
• Is the complete upgrade kit that also includes the Walbro 255LPH GSL392 pump, comes fully assembled, and ready to install with your stock LPFP.

• This kit includes the following:
• SAE J30R10 E85 compatible fuel line
• 14ga fuel resistant wiring harness
• Quick connect female bullet connectors (2)
• Vent tube replacement clip
• Nylon cable ties (10)
• Stainless steel lock nuts (2)
• 10ga/14ga stepdown butt splices w/E85 compatible heatshrink (2)
• Pushlock pump retention fittings (2)
• 14ga butt connectors w/heatshrink for pump removal to return to stock if/when desired (2)

• Recommended accessories:
• Lock Ring Removal Tool

•  Compatible with the following vehicle production dates:
• 1' E88          (11/2006 — 10/2013)
• 1' E82          (11/2006 — 10/2013)
• 3' E90         (02/2004 — 09/2008)
• 3' E90 LCI   (07/2007 — 12/2011)
• 3' E91          (02/2004 — 08/2008)
• 3' E91 LCI   (07/2007 — 05/2012)
• 3' E92         (05/2005 — 02/2010)
• 3' E92 LCI   (11/2008 — 06/2013)
• 3' E93          (09/2005 — 02/2010)
• 3' E93 LCI   (11/2008 — 10/2013)
• X1 E84        (04/2009 — 06/2015)

• Click on one of the links below to download your installation guide

*Note: Walbro does not warranty this pump for E85 use. If your application requires an E85 certified pump you may want to consider selecting a Stage 2 fuel kit.

** IMPORTANT:  Do NOT attempt to run this kit in line with our Stage 2 kit.  The Stage 2 kit is a higher flowing kit and this will not only restrict the flow of the stage 2 kit, it will result in failures.
